General Information
- Cylinder located inside of the runway, perfectly protected.
- Electrical protection devices in four columns ensure synchronization of runways
- Adjustable runways to accommodates different size vehicles
- ABS control box, 24v low voltage control system
- Hydraulic hose and cable protection system
- Single side manual lock release
- Heavy duty cables
- Top limit switch
- Aluminum motor with cooling fan
- CE certified
Technical Information |
|
| Lifting capacity : | 5000 kg |
| Min Height : | 130 mm |
| Lifting Height : | 1850 mm |
| Column Height : | 2225 mm |
| Width between platforms : | 928 mm |
| Total width : | 3120 mm |
| Total length excl. drive on ramps : | 4950 mm |
| Drive on ramps : | 600 mm |
| Power of motor : | 3.0 kw |
| Oil Pressure : | 18 MPa |
| Power Supply : | 220 v |
| Lifting time : | 50 s |
| Lowering Time : | 40 s |
